Oil Immersed Distribution Transformer for Power Distribution Rated Current 200.8/733.2 A Tapping Range ±2x2.5%

Product Description:

An Oil Immersed Power Transformer is a type of transformer specifically designed for power distribution applications. This particular product features a high-quality 45# Oil grade, ensuring optimal performance and reliability.

With a three-phase configuration, this Oil Immersed Distribution Transformer is suitable for a wide range of industrial and commercial power distribution systems. The three-phase design allows for efficient power transmission and distribution across various loads.

Utilizing the ONAN (Oil Natural Air Natural) cooling method, this Oil Immersed Power Transformer efficiently dissipates heat generated during operation, ensuring stable performance and longevity. The ONAN cooling method is known for its reliability and effectiveness in maintaining the transformer's temperature within safe operating limits.

The Tapping range of ±2x2.5% provides flexibility in adjusting the transformer's output voltage to meet specific power distribution requirements. This feature allows for precise voltage regulation, ensuring consistent and reliable power supply to connected loads.

With a rated capacity of 50/25KVA, this Oil Immersed Transformer is capable of handling moderate to heavy power loads with ease. The high-rated capacity ensures reliable and efficient power distribution, making it ideal for a variety of applications.

In summary, the Oil Immersed Power Transformer is a high-quality and reliable solution for power distribution needs. With its 45# Oil grade, three-phase configuration, ONAN cooling method, Tapping range of ±2x2.5%, and rated capacity of 50/25KVA, this transformer offers exceptional performance and durability for a wide range of industrial and commercial applications.

Features:

• Product Name: Oil Immersed Power Transformer
• Connection group: Dyn11
• Rated current: 200.8/733.2 A
• Rated frequency: 50Hz
• Insulation class: A
• Rated capacity: 50/25KVA

Technical Parameters:

Applications:

Oil Immersed Power Transformers, also known as Oil Immersed Distribution Transformers, are versatile and robust electrical devices that play a crucial role in power distribution systems. The Oil Immersed Transformer, model numbers S-M-50KVA or 25KVA, is a high-quality product originating from China and certified according to GB standards.

These transformers are designed for a wide range of application occasions and scenarios due to their excellent performance attributes. The Oil Immersed Transformer is especially suitable for use in industrial settings, commercial buildings, residential areas, and power plants. Its sturdy construction and reliable operation make it ideal for delivering a consistent power supply in various environments.

With a connection group of Dyn11, the Oil Immersed Transformer offers flexible installation options to meet specific requirements. The use of 45# Oil ensures efficient cooling and insulation properties, enhancing the transformer's overall performance and longevity. The transformer is designed to operate optimally at an ambient temperature of 25℃, providing stable power distribution even in challenging conditions.

One of the key features of the Oil Immersed Transformer is its high breakdown voltage of 60kV, ensuring reliable and safe operation under varying load conditions. The tapping range of ±2x2.5% allows for precise adjustments to voltage levels, making it suitable for applications where voltage regulation is critical.

When it comes to packaging, the Oil Immersed Transformer is securely packed on a wooden pallet to ensure safe transportation and handling. This robust packaging detail reflects the product's durability and reliability throughout its lifecycle.

Customization:

Product Customization Services for the Oil Immersed Power Transformer:

Brand Name: Oil Immersed Transformer

Model Number: S-M-50KVA or 25KVA

Place of Origin: CHINA

Certification: GB

Packaging Details: WOODEN PALLET

No. of phase: 3

Standard: IEC60076

Rated current: 200.8/733.2 A

Tapping range: ±2x2.5%

Ambient temperature: 25℃

Support and Services:

Our Product Technical Support and Services for the Oil Immersed Power Transformer include:

- Initial installation guidance and support.

- Routine maintenance recommendations and schedules.

- Troubleshooting assistance for any operational issues.

- Remote monitoring capabilities for real-time performance tracking.

- On-site repair and replacement services as needed.

- Training programs for operators and maintenance personnel.
